| PRODUCT INFORMATION – PRITY 1P36 D | |
|---|---|
| Type of fuel – Dry woods with a moisture content of ≤20% | |
| Energy efficiency class | А+ |
| Energy efficiency index (EEI) | 109 |
| Seasonal space heating energy efficiency (ηs) | 72,0 % |
| Room heating output | 10,9 kW |
| Flue gas temperature at nominal heat output | 150 °C |
| Energy efficiency at the nominal heat output | 82,0 % |
| Emission of combustion products at nominal heat output: | |
| CO (at 13% O2) | 971,0 mg/Nm3 |
| Dust (at 13% O2) | 34,1 mg/Nm3 |
| NOx (at 13% O2) | 101,7 mg/Nm3 |
| OGC (at 13% O2) | 100,5 mg/Nm3 |
| Exhaust gas mass flow rate | 13,4 g/s |
| Minimum chimney draft | 12 Pa |
| Flue diameter | Ø130 mm |
| Fuel consumption | 3,3 kg/h |
| Overall dimensions, L x B x H | 873 x 447 x 806 mm |
| Dimensions of the combustion chamber, L x B x H | 291 x 357 x 293 mm |
| Oven dimensions, L x B x H | 365 x 380 x 250 mm |
| Net weight | 107 kg |
| Materials used: Steel, cast iron, concrete, vermiculite, glass, heat-resistant paint. |
|
